MV Indoor Resin Cast Current Transformers
| Parameter | Specification |
|---|---|
| Construction | Epoxy Resin Cast |
| Type | Wound, Window |
| Reference Standard | IEC, IS or ANSI |
| System Voltage (Um) | Up to 36 kV |
| Insulation Level | 70/170 kVp |
| Rated Primary Current (Ipn) | Up To 5000 A |
| Rated Secondary Current (Isn) | 5A or 1A |
| Rated Short Time Current (Ith) | 50 kA |
| Rated Peak Current (Idyn) | 2.5 x Ith |
| Metering Accuracy Class | 0.2s, 0.2, 0.5s, 0.5, 1.0 or 3.0 |
| Protection Accuracy Class | 5P, 10P or 15P |
| Burden | As per client requirement |
| Insulation Class | B or higher |
| Frequency | 50 or 60 Hz |
